Specifications: Dimensions
When opened
Thickness: 5.9 mm (Voyager Black variant)
Thickness: 5.8 mm (Emerald Dusk variant)
Width: 143.1 mm
Height: 153.4 mm
When closed
Thickness: 11.9 mm (Voyager Black variant)
Thickness: 11.7 mm (Emerald Dusk variant)
Width: 73.3 mm
Height: 153.4 mm
Weight
Emerald Dusk: 245g
Voyager Black: 239g
Display
Main display
Certification: TÜV Rheinland Intelligent Eye Care
Protective Material: Ultra Thin Glass
Pulse-Width Modulation: 1440 Hz
Touch response: Up to 240 Hz
97% NTSC / 100% DCI-P3
Support sRGB, DCI-P3, 10-bit Color Depth
Typical (HBM) / Peak Brightness: 1400 / 2800 nits
Panel Type: Flexi-fluid AMOLED with LTPO 3.0
Refresh Rate: 1-120 Hz dynamic
Screen-to-body ratio: 89.6%
Aspect Ratio: 1.0758:1
Resolution: 2440*2268 (2K), 426 ppi
Size: 7.82", measured diagonally from corner to corner
Cover screen
Certification: TÜV Rheinland Intelligent Eye Care
Protective Material: Ceramic Guard
Touch response: Up to 240 Hz
Typical (HBM) / Peak Brightness: 1400 / 2800 nits
Support sRGB, DCI-P3, 10-bit Color Depth
97% NTSC / 100% DCI-P3
Panel Type: Super Fluid AMOLED with LTPO 3.0
Refresh Rate: 10-120 Hz dynamic
Screen-to-body ratio: 91.8%
Aspect Ratio: 20:09
Resolution: 2484*1116 (2K), 431 ppi
Size: 6.31", measured diagonally from corner to corner
Performance
Operating System
OxygenOS 13.2 based on Android™ 13
CPU
Qualcomm® Snapdragon™ 8 Gen 2 Mobile Platform
5G Chipset
X70
GPU
Adreno 740
RAM
16GB LPDDR5X with RAM-Vita
RAM Expansion
4/8/12GB
Storage
512GB UFS 4.0
Battery
4,805 mAh (Dual-cell, 3295+1510 mAh, non-removable)
default
67W SUPERVOOC Charging
Haptics
X-axis motor
Certification
TÜV SÜD 48-month Fluency Rating A
Camera
Main Camera
Autofocus: Yes
Field of View: 85°
Aperture: ƒ/1.7
Focal Length: 24 mm equivalent (1X), 47 mm equivalent (2X)
Electronic Image Stabilization: Yes
Optical Image Stabilization: Yes
Lens Quantity: 7P
Pixel Size: 1.12 µm
Megapixels: 48
Sensor Size: 1/1.43"
Sensor: Sony LYT-T808 "Pixel Stacked" CMOS
Telephoto
Ultra Res (digital) Zoom: Up to 120X
Autofocus: Yes
Field of View: 33.4°
Aperture: ƒ/2.6
Focal Length: 70 mm equivalent (3X), 145 mm equivalent (6X)
Electronic Image Stabilization: Yes
Optical Image Stabilization: Yes
Lens Quantity: 4P
Pixel Size: 0.7 µm
Megapixels: 64
Sensor Size: 1/2"
Sensor: OmniVision OV64B with 3X optical zoom, 6X in-sensor zoom
Ultra-wide Angle
Macro: 3.5 cm
Autofocus: Yes
Field of View: 114°
Aperture: ƒ/2.2
Electronic Image Stabilization: Yes
Lens Quantity: 6P
Pixel Size: 0.8 µm
Megapixels: 48
Sensor Size: 1/2"
Sensor: Sony IMX581
Imagine if you could be satisfied and content with your purchase. That can very much be your reality with the OnePlus OPEN 5G (16/512GB).
Inventory Last Updated: Sep 07, 2024
